6. Working Advice

Always place the measuring tool level on the oor or fasten it plane against the wall. When placing down or

fastening unevenly, the angle will not be precisely 90°. The measuring tool is not self-levelling. When lay-

ing oor tiles, do not use spirit levels 3 for levelling of the measuring tool. Spirit levels 3 are used only for

alignment against walls.

When laying oor tiles, the bubbles of the spirit levels can be within the marks, without the measuring tool

being level. The reference point for alignment of tiles is the intersecting of the laser lines, directly in front of

the measuring tool. To project an angle, the measuring tool must be rotated at this intersecting point.

7. Positioning the Measuring Tool

When working on the oor, place down the measuring tool with the bottom plate 8 facing the oor. Place the

T-edge 5 of the tool against a wall so that the 0° laser line runs parallel to the reference line (e.g. a wall).

Measure the clearance between laser line and reference line directly at the measuring tool and as far away

as possible from the measuring tool.

Align the measuring tool in such a manner that both clearances are equal. When working on a wall, rstly

fasten the wall holder 11 to the wall, e.g. by placing the wall holder via an opening onto a screw that lightly

projects out of the wall. Then tighten the screw to secure the wall holder. Fasten the measuring tool with

the magnets 6 against the wall holder 11. Spirit levels 3 aid in precisely positioning the laser line against

the wall.
