Ada tempro-pocket [5/30] Tem pro pocket

TemPro-pocket

4. Lock mode: press MODE three times, LOCK will flash on display, then confirm the lock mode by pressing MEAS. The thermometer

will continuously display the temperature. Press MODE again to exit lock mode.

5. Measuring unit switch: press MODE four times, current unit symbol “°C” or “°F” will flash on display, then press MEAS again to

switch to “°F” or “°C”.

6. Emissivity adjustment: firstly press MODE five times and the emissivity symbol E will flash, then press MEAS to display current

emissivity. Increase the emissivity value by 0.01 each time press MEAS. Press MODE to confirm the setting value and exit adjustment

mode. The emissivity range is 0.1 to 1.0.

7. Laser on/off: turn on the thermometer by directly pressing MEAS, the laser will be on; hold MODE and then press MEAS to turn on

the unit with laser off.

8. When thermometer battery is low, the low power indicator will be shown on the upper part of the LCD screen. Change the laser

battery when laser beam become weak, dim or simply off.

9. Hold MODE for two seconds to power off the thermometer.

Battery replacement

1. Install: two CR2032 cell is needed, one to power the measuring module and the other to power the laser module. Keep pressure on the

raised spot located on the battery lid and turn it clockwise to open the battery compartment, place the cells and close the lid.

2. Insert a pin shape object into the pin slot to pry the cell.

Temperature measuring

1. Point the thermometer to the target object and press MEAS to get temperature readings.

2. Measuring distance and measuring spot: referring to illustration below, for highest accuracy, the distance and diameter of measuring

spot ratio D:S should be equal to or less than 6 to 1. The target surface should be larger than the field of view, as the distance increases,

the measuring spot will increase as well.
