Connect the Unit with a Camera Probe

Connect the inspection unit with a camera probe before operation. To connect the probe to the unit,

make sure the keyed ends are properly aligned (Fig7). Tighten the knob when they are aligned and

Accessories installation

A. Accessories installation of standard 12mm probe

For the three accessories shown in Fig.2 (magnetic tip, hook tip, mirror tip), hold the camera head and slip the semicircle end of the accessory

over the camera head as shown in Fig.8. Rotate the accessory by 90 degrees to a fixed position, as shown in Fig.9.
