Приложение F. Нормативно-правовые положения Lenovo

Caution: To comply with FCC RF exposure compliance requirements, a separation distance

of at least 20 cm (8 inches) must be maintained between the antennas for the integrated

Wireless LAN/WiMAX Mini PCI Express Cards built into the screen section and all

persons. You are not allowed to disable “sleep (standby) mode” for the power

management function, if you cannot maintain the sufficient antenna separation (at least

20 cm) in any case the LCD is left opened or closed.

ii) FCC ID of wireless module:

On the bottom side of your Lenovo computer, you will find an indicator label of the format

“Contains Transmitter Module: FCC ID XXXX”, where XXXX represents the FCC ID that

corresponds to your preinstalled Wireless LAN/WiMax module.

iii) Radio Frequency interference requirements:

• The devices have been tested and found to comply with the limits for a Class B digital

device pursuant to FCC Part 15 Subpart B. Refer to “Electronic emission notices” on

page 75. The models R5B95, AR5B93, BCM94313HMG2L, BCM943225HM, 112BNHMW,

622ANHMW, 622ANXHMW underwent the certification process with each respective

FCC ID number listed in “I. Factory preinstalled Wireless LAN/WiMAX module” on

page 70.

• Each device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency

range. FCC requires these products to be used indoors for the frequency range 5.15 to

5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite

systems.

• High power radar are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to

5.85 GHz bands. These radar stations can cause interference with and/or damage this

device.

II. Preinstalled integrated Bluetooth module

• FCC ID: QDS-BRCM1043 (Model: BCM92070MD_REF)

i) FCC ID and installation of the module:

If you find an indication “Contains Transmitter Module: FCC ID: QDS-BRCM1043” on the

label at the bottom side of your computer, your computer contains the Bluetooth transmitter

module (Model: BCM92070MD_REF). The Bluetooth module is preinstalled by Lenovo, and

is not removable by users.

Note: The transmission diversity function is implemented for this product. For WLAN card (Model:

112BNHMW, AR5B95, AR5B93, BCM94313HMG2L, BCM943225HM) using Main and Auxiliary

antennas for transmission in the IEEE 802.11 b/g transmission mode, radio frequency energy is

not emitted simultaneously from both Main and Auxiliary antennas. One of the antennas is

selected automatically or manually (by users) to have good quality of radiocommunication

(transmission diversity function). For WLAN cards (112BNHMW, AR5B95, AR5B93,

BCM94313HMG2L, BCM943225HM, 622ANHMW, 622ANXHMW) in the IEEE 802.11 a/b/g, or

MIMO ( Multiple In Multiple Out ) transmission mode, the radio frequency energy is emitted

from Main antenna.
