ASRock h81m-vg4 [21/78] Installing the cpu
![ASRock h81m-vg4 [21/78] Installing the cpu](/views2/1159390/page21/bg15.png)
H81M-HG4/H81M-DG4/H81M-VG4
17
English
2.1 Installing the CPU
1. Before you insert the 1150-Pin CPU into the socket, please check if the PnP cap is on
the socket, if the CPU surface is unclean, or if there are any bent pins in the socket.
Do not force to insert the CPU into the socket if above situation is found. Otherwise,
the CPU will be seriously damaged.
2. Unplug all power cables before installing the CPU.
2
1
A
B
