![ASRock h81 pro btc [6/75] Speciications](/views2/1159417/page6/bg6.png)
2
English
1.2 Specications
Platform
•
ATX Form Factor
•
All Solid Capacitor design
CPU
•
Supports 4
th
Generation Intel® Core
TM
i7 / i5 / i3 / Xeon® /
Pentium® / Celeron® in LGA1150 Package
•
Digi Power design
•
4 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H81
Memory
•
Dual Channel DDR3 Memory Technology
•
2 x DDR3 DIMM Slots
•
Supports DDR3 1600/1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 16GB
(see CAUTION1)
•
Supports Intel® Extreme Memory Prole (XMP)1.3/1.2
Expansion
Slot
•
1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)
•
5 x PCI Express 2.0 x1 Slots
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 4400/4600
•
Pixel Shader 5.0, DirectX 11.1
•
Max. shared memory 1792MB
•
Dual Graphics Output: support HDMI and D-Sub ports by
independent display controllers
•
Supports HDMI Technology with max. resolution up to
1920x1200 @ 60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
