ASRock fm2a88m-hd+ [16/64] English
![ASRock fm2a88m-hd+ [16/64] English](/views2/1159457/page16/bg10.png)
FM2A88M-HD+
11
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5 ATX Power Connector (ATXPWR1)
6 SATA3 Connector (SATA _ 8)
7 SATA3 Connector (SATA _7)
8 Chassis Speaker Header (SPEAKER1)
9 System Panel Header (PANEL1)
10 SATA3 Connector (SATA _1)
11 SATA3 Connector (SATA _ 2)
12 TPM Header (TPMS1)
13 Chassis Fan Connector (CHA_FAN1)
14 SATA3 Connector (SATA _4)
15 SATA3 Connector (SATA_3)
16 SATA3 Connector (SATA _6)
17 SATA3 Connector (SATA _ 5)
18 USB 2.0 Header (USB6_7)
19 USB 2.0 Header (USB8_9)
20 USB 3.0 Header (USB_10_11)
21 Print Port Header (LPT1)
22 COM Port Header (COM1)
23 Front Panel Audio Header (HD_AUDIO1)
24 Clear CMOS Jumper (CLRCMOS1)
25 Chassis Intrusion Header (CI1)
