FM2A88X Pro3+
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
TM
2.0: New video post
processing capability for automatic jitter reduction on
home/online video
Supports Full HD 1080p Blu-ray (BD) playback with
Audio
5.1 CH HD Audio (Realtek ALC662 Audio Codec)
Supports Surge Protection (ASRock Full Spike Protec-
tion)
LAN
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
Realtek RTL8111GR
Supports Wake-On-WAN (see CAUTION 3)
Supports Wake-On-LAN
Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
Supports LAN Cable Detection
Supports PXE
Rear
Panel I/O
1 x PS/2 Mouse Port
1 x PS/2 Keyboard Port
1 x D-Sub Port
4 x USB 2.0 Ports (Supports ESD Protection (ASRock
Full Spike Protection))
2 x USB 3.0 Ports (AMD A88X (Bolton-D4))
(Supports ESD Protection (ASRock Full Spike
Protection))
1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID
0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot
Plug
