![ASRock z170 extreme4 [8/100] Chipset](/views2/1159493/page8/bg8.png)
2
English
1.2 Specications
Platform
•
ATX Form Factor
•
High Density Glass Fabric PCB
CPU
•
Supports 6
th
Generation Intel® Core
TM
i7/i5/i3/Pentium®/
Celeron® Processors (Socket 1151)
•
Digi Power design
•
10 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
•
Supports Intel® K-Series unlocked CPUs
•
Supports ASRock BCLK Full-range Overclocking
•
Supports ASRock Hyper BCLK Engine
Chipset
•
Intel
®
Z170
Memory
•
Dual Channel DDR4 Memory Technology
•
4 x DDR4 DIMM Slots
•
Supports DDR4 3200+(OC)*/2933(OC)/2800(OC)/2400
(OC)/2133 non-ECC, un-buered memory
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
•
Max. capacity of system memory: 64GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
•
15 Gold Contact in DIMM Slots
Expansion
Slot
•
3 x PCI Express 3.0 x16 Slots (PCIE2/PCIE4/PCIE6: single
at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4); triple at x8
(PCIE2) / x8 (PCIE4) / x4 (PCIE6))
•
3 x PCI Express 3.0 x1 Slots (Flexible PCIe)
•
Supports AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
and CrossFireX
TM
•
Supports NVIDIA® Quad SLI
TM
and SLI
TM
•
15 Gold Contact in VGA PCIe Slot (PCIE2)
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
