1.2 Specications
Platform
•
ATX Form Factor
•
Premium Gold Capacitor design (100% Japan-made high-
quality conductive polymer capacitors)
•
High Density Glass Fabric PCB
CPU
•
Supports Socket AM3+ processors
•
Supports Socket AM3 processors: AMD Phenom
TM
II X6
/ X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 /
Sempron processors
•
Supports 8-Core CPU
•
Supports UCC feature (Unlock CPU Core)
•
Digi Power design
•
8 + 2 Power Phase design
•
Supports CPU up to 140W
•
Supports AMD's Cool 'n' Quiet Technology
•
FSB 2600 MHz (5.2 GT/s)
•
Supports Untied Overclocking Technology
•
Supports Hyper-Transport 3.0 (HT 3.0) Technology
Chipset
•
Northbridge: AMD 990FX
•
Southbridge: AMD SB950
Memory
•
Dual Channel DDR3 Memory Technology
•
4 x DDR3 DIMM Slots
•
Supports DDR3 2450(OC)/2100(OC)/1600/1333/1066 non-
ECC, un-buered memory (see CAUTION1)
•
Max. capacity of system memory: 64GB (see CAUTION2)
•
Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2
•
Supports AMD Memory Prole (AMP)
Expansion
Slot
•
3 x PCI Express 2.0 x16 Slots (PCIE2/PCIE3 @ x16 mode;
PCIE5 @ x4 mode)
•
2 x PCI Express 2.0 x1 Slots
•
Supports AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
and
CrossFireX
TM
•
Supports NVIDIA® Quad SLI
TM
and SLI
TM
