ASRock fatal1ty 990fx killer/3.1 [11/84] English
![ASRock fatal1ty 990fx killer/3.1 [11/84] English](/views2/1159550/page11/bgb.png)
Fatal1ty 990FX Killer/3.1 Series
3
English
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC1150
Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Purity Sound
TM
2
- Nichicon Fine Gold Series Audio Caps
- 115dB SNR DAC with Dierential Amplier
- TI® NE5532 Premium Headset Amplier (Supports up to
600 Ohm headsets)
- Direct Drive Technology
- EMI Shielding Cover
- PCB Isolate Shielding
•
Supports DTS Connect
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Qualcomm® Atheros® Killer
TM
E2200 Series
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Mouse Port
•
1 x PS/2 Keyboard Port
•
1 x Optical SPDIF Out Port
•
5 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•
1 x Fatal1ty Mouse Port (USB 2.0) (Supports ESD Protection
(ASRock Full Spike Protection))
•
4 x USB 3.0 Ports (ASMedia Hub) (Supports ESD Protection
(ASRock Full Spike Protection))
•
1 x eSATA3 Connector
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
