12
1.3 Motherboard Layout
FSB800
DDR3_A1 (64 bit, 240-pin module)
DDR3_A2 (64 bit, 240-pin module)
FSB800
DDR3_B1 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
AMD
SB950
Chipset
HD_AUDIO1
1
HDLED RESET
PLED PWRBTN
1
PANEL 1
SPEAKER1
1
24.4cm (9.6-in)
30.5cm (12.0-in)
SATA3_4_5
AMD
970
Chipset
SATA3_2_3
USB_6_7
1
FRONT_1394
11
PWRBTN1
RSTBTN1
Dr.
Debug
PS2
Keyboard
RJ-45 LAN
eSATA3
IEEE 1394
USB 2.0
T: USB2
B: USB3
USB 2.0
T: U SB0
B: USB1
CHA_FAN1
Coaxial
SPDIF
Optical
SPDIF
Clr
CMOS
USB 3.0
T: US B4
B: USB5
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
CTR BASS
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
SOCKET AM3b
SATA3_1
PS2
Mouse
CIR1
1
CHA_FAN2
CHA_FAN3
USB_8_9
1
USB_10_11
1
COM1
1
IR1
1
HDMI_SPDIF1
PCIE4
PCIE5
PCIE3
PCIE2
PCIE1
PCI1
PCI2
CMOS
BATTERY
AUDIO
CODEC
ATX12V1
CPU_FAN2
PWR_FAN1
CPU_FAN1
LAN
PHY
1
PLED1
CLRCMOS1
1
USB 3.0
140W CPU
DDR3 2000+
AM3+
1394a
Designed in Taipei
RoHS
SATA3 6Gb/s
Front USB 3.0
970 Extreme4
ErP/EuP Ready
USB_12_13
Support 8-Core CPU
32Mb
BIOS
Super
I/O
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
24
2526
27
28
29
3031
32
33
34
35
36
37
38
39
40
22
41
42
X
FAST USB
1 ATX 12V Power Connector (ATX12V1) 23 Power Switch (PWRBTN)
2 Power Fan Connector (PWR_FAN1) 24 Front Panel IEEE 1394 Header
3 CPU Fan Connector (CPU_FAN2) (FRONT_1394, White)
4 CPU Fan Connector (CPU_FAN1) 25 Chassis Fan Connector (CHA_FAN2)
5 AM3+ CPU Socket 26 Chassis Fan Connector (CHA_FAN3)
6 CPU Heatsink Retention Module 27 USB 2.0 Header (USB_6_7, Blue)
7 2 x 240-pin DDR3 DIMM Slots 28 Consumer Infrared Module Header
(Dual Channel A: DDR3_A1, DDR3_B1; Blue) (CIR1)
8 2 x 240-pin DDR3 DIMM Slots 29 USB 2.0 Header (USB_8_9, Blue)
(Dual Channel B: DDR3_A2, DDR3_B2; White) 30 USB 2.0 Header (USB_10_11, Blue)
9 Chassis Fan Connector (CHA_FAN1) 31 COM Port Header (COM1)
10 ATX Power Connector (ATXPWR1) 32 Infrared Module Header (IR1)
11 USB 3.0 Header (USB_12_13, Blue) 33 HDMI_SPDIF Header
12 Northbridge Controller (HDMI_SPDIF1, White)
13 Southbridge Controller 34 PCI Express 2.0 x16 Slot (PCIE5; Blue)
14 SATA3 Connector (SATA3_4_5, White) 35 SPI Flash Memory (32Mb)
15 SATA3 Connector (SATA3_2_3, White) 36 PCI Slot (PCI2)
16 SATA3 Connector (SATA3_1, White) 37 PCI Express 2.0 x16 Slot (PCIE4; Blue)
17 Dr. Debug (LED) 38 PCI Express 2.0 x1 Slot (PCIE3; White)
18 Power LED Header (PLED1) 39 PCI Slot (PCI1)
19 Clear CMOS Jumper (CLRCMOS1) 40 PCI Express 2.0 x16 Slot (PCIE2; Blue)
20 Chassis Speaker Header (SPEAKER 1, White) 41 PCI Express 2.0 x1 Slot (PCIE1; White)
21 System Panel Header (PANEL1, White) 42 Front Panel Audio Header
22 Reset Switch (RSTBTN) (HD_AUDIO1, White)
