![Asus z87m-plus [13/164] Check your motherboard package for the following items](/img/pdf.png)
Asus z87m-plus [13/164] Check your motherboard package for the following items
![Asus z87m-plus [13/164] Check your motherboard package for the following items](/views2/1159681/page13/bgd.png)
xiii
• If any of the above items is damaged or missing, contact your retailer.
• The illustrations above are for reference only. Actual product specications may vary
with different models.
User Manual
ASUS Z87M-PLUS motherboard
User manual Support DVD
2 x Serial ATA 6.0 Gb/s cables 1 x ASUS Q-Shield
Package contents
Check your motherboard package for the following items
