xi
USB
Intel
®
Z97 Express Chipset - supports ASUS USB 3.0
Boost
- 4 x USB 3.0/2.0 ports at rear panel (blue)
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at rear
panel)
ASMedia
®
USB 3.0 controllers - support ASUS USB 3.0
Boost
- 4 x USB 3.0/2.0 ports at mid-board for front panel support
- 2 x USB 3.0/2.0 ports at rear panel (blue)
ASUS Exclusive
Features
High Performance
5-Way Optimization by Dual Intelligent Processors 5
- Whole system optimization with a single click! 5-Way
Optimization tuning key perfectly consolidates TPU, EPU,
DIGI+ Power Control, Fan Xpert 3, and Turbo APP together,
providing better CPU performance, efcient power saving,
precise digital power control, whole system cooling and even
tailor your own app usages.
DIGI+ Power Control
CPU Power
- Industry leading digital 16-phase power design
- ASUS CPU power utility
DRAM Power
- Industry leading digital 2-phase DRAM power design
- ASUS DRAM power utility
TPU
- Auto Tuning, TPU, GPU Boost, 2-level TPU switch
EPU
- EPU, EPU switch
ASUS Fan Xpert3
- Featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control.
Turbo App
- Featuring automatic system performance tuning, network
priority, and audio scene conguration for selected
applications.
UEFI BIOS
- Most advanced options with fast response time
M.2 and SATA Express onboard
- The latest transfer technologies with up to 10 Gb/s data
transfer speeds
Special Memory O.C. Design
- Superb memory O.C. capability under full load by minimizing
the coupling noise and signal reection effect
(continued on the next page)
Z97-DELUXE specifications summary
