xi
(continued on the next page)
SABERTOOTH Z97 MARK 2 specifications summary
Other Special Features
- USB 3.0 Boost featuring speedy USB 3.0 transmission
- USB BIOS Flashback with USB BIOS Flashback Wizard for EZ
BIOS download scheduling
- USB Charger+ featuring quick-charging function for all smart
devices
- ASUS Remote GO! with Cloud GO!, Remote Desktop, Remote
Keyboard & Mouse, File Transfer
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user
interface
- Turbo LAN to experience smooth online gaming with lower pings
and less lags
- Push Notice monitors your PC status with smart devices in real
time
- AI Suite 3
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- EZ Update
- Disk Unlocker
- ASUS EZ Flash 2
- Multi-language BIOS
Rear Panel I/O Ports
1 x DisplayPort
1 x HDMI port
1 x Optical S/PDIF Output
1 x USB BIOS Flashback Button
1 x LAN (RJ45) port
4 x USB 3.0/2.0 ports (blue, 1 supports USB BIOS Flashback)
4 x USB 2.0/1.1 ports
8-channel Audio I/O ports
SABERTOOTH_Z97_M2_User_Guide.indb 11 4/28/2014 4:52:56 PM
