xii
Internal I/O connectors
2 x USB 3.0/2.0 connectors support additional 4 USB 3.0/2.0 ports
(19-pin; moss green)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
6 x SATA 6Gb/s connectors (brown)
1 x CPU Fan connector (4-pin moss green) for both 4-pin(PWM
mode) and 3-pin(DC mode) CPU coolers control with auto
detection support
1 x CPU OPT Fan connector (4-pin Black) for both 4-pin(PWM
mode) and 3-pin(DC mode) CPU coolers control
4 x Chassis Fan connectors (4-pin Black) for both 4-pin(PWM
mode) and 3-pin(DC mode) CPU coolers control
2 x Assistant Fan connectors (3-pin White)
Front panel audio connector (AAFP)
24-pin EATX Power connector
8-pin EATX 12V Power connector
System Panel (Q-Connector)
1 x MemOK! Button
1 x DRCT (DirectKey) header
3 x T_Sensor (Thermal Sensor) headers
1 x S/PDIF Out header
1 x TPM header
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX series
support
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM
BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS
CrashFree BIOS 3, My Favorites, Quick Note, Last Modied Log,
F12 PrintScreen function, F3 Shortcut functions, and ASUS DRAM
SPD (Serial Presence Detect) memory information
Accessories
4 x Serial ATA 6Gb/s cables
1 x ASUS SLI bridge connector 7cm
1 x ASUS Q-Shield
1 x 2 in 1 Q-connector
1 x TUF Inside sticker
1 x TUF Certication card
1 x TUF 5 Year Warranty manual (by region)
1 x User’s manual
Manageability WfM 2.0, DMI 2.7, WOL by PME, PXE
Support DVD contents
Drivers
Anti-virus software (OEM version)
ASUS/TUF CPU-Z
ASUS Utilities
Form factor
ATX form factor: 12.0 in. x 9.6 in. (30.5 cm x 24.4 cm)
SABERTOOTH Z97 MARK 2 specifications summary
Specications are subject to change without notice.
SABERTOOTH_Z97_M2_User_Guide.indb 12 4/28/2014 4:52:56 PM
