Asus x750ln, 90nb05n1-m01520 [28/114] One finger gestures

Notebook PC E-Manual

One-nger gestures

Tap/Double tap

• In the Start screen, tap an app to launch it.

• In Desktop mode, double-tap an application to launch it.

Drag and drop

Double-tap an item, then slide the same nger without lifting it o the

touchpad. To drop the item to its new location, lift your nger from the

touchpad.
