Asus x750ln, 90nb05n1-m01520 [70/114] Power4gear hybrid

Notebook PC E-Manual

Power4Gear Hybrid

Optimize the performance of your Notebook PC using the power saving

modes in Power4Gear.

NOTE: Unplugging the Notebook PC from its power adapter automatically

switches Power4Gear Hybrid to Battery Saving mode.

Launching Power4Gear Hybrid

Press .
