Chapter 1: Product introduction

1-8

1.7.3 HDD status LED

HDD status LED

SATA/SAS HDD LED Description

HDD Status

LED

GREEN ON SATA/SAS HDD power ON

RED ON

HDD has failed and should be swapped

immediately

GREEN/

RED

Blinking RAID rebuilding

GREEN/

RED

OFF HDD not found

HDD Activity

LED

GREEN Blinking Read/write data from/into the SATA/SAS HDD

HDD Activity LED
