Asus rs700-e8-rs4 [20/198] Chassis cover

Chapter 2: Hardware setup

2-2

2.1 Chassis cover

2. Firmly hold the cover and slide it toward the rear panel for about half an inch until it is

disengaged from the chassis.

3. Lift the cover from the chassis.

1. Loosen the thumbscrew on the rear panel to release the rear cover from the chassis.

Removing the rear cover

To remove the rear cover:
