GR6
9
Power button
The power button allows you to turn the GR6 on or o.
Steam Big Picture Launcher
The Steam Big Picture Launcher allows you to access Steam
Big Picture mode from power o, sleep, hibernate,
or Windows® operating system.
Headphone jack
The stereo headphone jack is used to connect the system’s
audio out signal to headphones.
Microphone jack
The microphone jack is designed to connect the
microphone used for video conferencing, voice narrations,
or simple audio recordings.
USB 2.0 ports (with USB charger feature)
The USB (Universal Serial Bus) 2.0 ports are compatible
with USB 2.0/1.1 devices such as keyboards, mouse
devices, cameras, and hard disk drives.
The USB 2.0 port with the icon comes with a USB
Charger feature that allows charging of mobile devices
even while your GR6 is on sleep, hibernate, or power o
state.
