Asus rog maximus viii hero [103/194] Chapter 3
![Asus rog maximus viii hero [103/194] Chapter 3](/views2/1162354/page103/bg67.png)
ASUS MAXIMUS VIII HERO
3-27
Chapter 3
ASPM Support [Disabled]
Select the ASPM level for energy saving conditions.
Conguration options: [Disabled] [L0s] [L1s] [L0sL1] [Auto]
SA - PCI Express
DMI Link ASPM Control [Disabled]
This item is for the control of the Active State Power Management on SA side of the DMI link.
Conguration options: [Disabled] [L1]
PEG ASPM [Disabled]
This item is for the control of the Active State Power Management for the PEG 0.
Conguration options: [Disabled] [Auto] [ASPM L0s] [L1] [L0sL1]
