viii
Z170-K specifications summary
Specifications
ASUS
unique
features
ASUS Fan Xpert 3
- Featuring Fan Auto Tuning function and multiple thermistors selection for optimized
system cooling control
ASUS EPU
- EPU
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
UEFI BIOS
- Most advanced options with fast response time
USB 3.1 Boost
- featuring speedy USB 3.1 transmission
Gaming Scenario
Audio Features
- Audio that roars on the battleeld
Media Streamer
- Pipe music or movies from your PC to a smart TV, your entertainment goes
wherever you go
- Media Streamer app for portable smartphone/tablet, supporting iOS 7 & Android
4.0 systems
ASUS Exclusive Features
- ASUS AI Charger+
- ASUS AI Suite 3
- ASUS Disk Unlocker featuring 3TB + HDD support
EZ DIY
Push Notice
- Monitor your PC status with smart devices in real time
UEFI BIOS EZ Mode
- Featuring friendly graphics user interface
- ASUS O.C. Tuner
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS Anti Surge
Q-Design
- ASUS Q-DIMM
- ASUS Q-Slot
ASUS
quiet
thermal
solution
Quiet Thermal Design
- ASUS Fan Xpert 3
- Stylish Fanless Design: PCH heatsink and MOS heatsink solution
(continued on the next page)
