vii
Z170-P specifications summary
(continued on the next page)
Specifications
Storage
Intel
®
Z170 Express Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology
14 support
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (both
SATA & PCIE mode)
- 4 x SATA 6.0 Gb/s ports
- Supports Intel
®
Smart Response Technology*
* These functions work depending on the type of CPU installed.
LAN
Realtek
®
RTL8111H Gigabit LAN controller supports ASUS LANGuard
Audio
Realtek
®
ALC887 8-channel High Denition Audio CODEC
- LED-illuminated design: Brighten up your build with the gorgeous illuminated
audio trace path
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced
multi-lateral interference, and comes with a gorgeous illuminated trace path
- Dedicated audio PCB layers: Separate layers for left and right channels to guard
the quality of the sensitive audio signals
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive
sound with exceptional clarity and delity
- Supports jack-detection, and front panel jack-retasking
USB
Intel
®
Z170 Express Chipset
- 1 x 5Gb/s USB Type C port (@back panel) support 3A power output
- 6 x USB 3.0/2.0 ports (4 ports @mid-board; 2 ports @back panel, blue, Type A)
- 6 x USB 2.0/1.1 ports (4 ports @mid-board; 2 ports @back panel)
ASUS
unique
features
ASUS 5X PROTECTION II
- ASUS LANGuard - Protects against LAN surges, lightning strikes and static-
electricity discharges
- ASUS Overvoltage Protection - World-class circuit-protecting power design
- ASUS DIGI+ VRM - 4+2+1 phase digital power design
- ASUS DRAM Overcurrent Protection: Enhanced DRAM overcurrent protection
- ASUS Stainless Steel Back I/O - 3X corrosion-resistance for greater durability
Superb Performance
M.2 onboard
- The latest transfer technologies with up to 32Gb/s data transfer speeds
ASUS Fan Xpert 3
- Featuring Fan Auto Tuning function and multiple thermistors selection for
optimized system cooling control
ASUS EPU
- EPU
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
UEFI BIOS
- Most advanced options with fast response time
USB 3.0 Boost
- featuring speedy USB 3.0 transmission
