Asus z170-deluxe [10/186] Z170 deluxe specifications summary
![Asus z170-deluxe [10/186] Z170 deluxe specifications summary](/views2/1162365/page10/bga.png)
x
(continued on the next page)
Z170-DELUXE specifications summary
Storage
ASMedia
®
SATA 6Gb/s controller****
- 2 x SATA 6Gb/s ports (black)
* Supports PCIE RAID configurations via onboard M.2 and PCIEX16_3 slot
storages.
**
The M.2 socket shares SATA ports with SATA Express. Adjust BIOS
settings to use an M.2 SATA device.
***
These functions will work depending on the CPU installed.
****
These SATA ports are for data hard drivers only. ATAPI devices are not
supported.
LAN
Gigabit Intel LAN connection - 802.3az Energy Efcient Ethernet (EEE)
appliance
Intel
®
I219-V Gigabit LAN - Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Intel
®
I211-AT Gigabit LAN controller
ASUS LAN Guard
ASUS Turbo LAN Utility
Wireless Data
Network
Speedy Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz
Up to 1300Mbps transfer speed
ASUS Wi-Fi GO! Utility
Bluetooth
Bluetooth v4.0
Audio
Realtek
®
ALC1150 8-channel high denition audio CODEC featuring
Crystal Sound 3
- Separate layer for left and right track, ensuring both sound deliver
equal quality
- Top notch audio sensation delivers according to the audio
conguration
- Audio shielding ensures precise analog/digital separation and greatly
reduced multi-lateral interference
- Audio Amplier to enhance the highest quality sound for headphone
and speakers
- Premium Japan-made audio capacitors provides warm, natural, and
immersive sound with exceptional clarity and delity
- High quality 112dB SNR stereo playback output (Line-out@back) &
104dB SNR recording input (Line-in) support
- Absolute Pitch 192khz/24bit true BD lossless sound
- BD audio layer content protection
- DTS Studio Sound
- DTS Connect
- Supports jack-detection, multi-streaming, front panel jack-retasking
(MIC)
- Optical S/PDIF out port at back I/O
