Asus z170-deluxe [11/186] Superb performance
![Asus z170-deluxe [11/186] Superb performance](/views2/1162365/page11/bgb.png)
xi
USB
Intel
®
Z170 Express Chipset- supports ASUS USB 3.1 Boost
- 5 x USB 3.0/2.0 ports (4 ports @mid-board, 1 port @back panel, blue)
- 5 x USB 2.0/1.1 ports (4 ports @mid-board, 1 port @back panel)
ASMedia
®
USB 3.1 controllers- supports ASUS USB 3.1 Boost and 3A
power output
- 5 x USB 3.1/3.0/2.0 ports @back panel (teal blue, Type A)
- 1 x USB 3.1/3.0/2.0 port @back panel (Type C)
ASUS Exclusive
Features
Superb Performance
OC Design: ASUS PRO Clock Technology
- Full BCLK range for extreme overclocking performance.
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates better
CPU performance, power saving, digital power control, system cooling and
app usages.
DIGI+ Power Control
- CPU Power: Digital 16-phase power design
- iGPU Power: Digital 4-phase power design
- DRAM Power: Digital 2-phase power design
TPU
- Auto Tuning, GPU Boost, 2-level TPU switch
EPU
- EPU, EPU switch
Fan Xpert 3 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
Turbo App featuring system performance tuning, network priority, and audio
scene conguration for selected applications.
UEFI BIOS
- Most advanced options with fast response time
Special Memory O.C. Design
- Superb memory O.C. capability under full load by minimizing the coupling
noise and signal reection effect
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
Seamless Entertainment
Wi-Fi GO!
- Wi-Fi GO! Function: Cloud GO!, Remote Desktop, Remote Keyboard &
Mouse, File Transfer
- Wi-Fi GO! & NFC Remote app for portable smartphone/tablet, supporting
iOS 7 & Android 4.0 systems
(continued on the next page)
Z170-DELUXE specifications summary
