2.7.5 Chassis Fan 1/2 Q-Fan Control [DC Mode]
[PWMmode] EnablesthechassisQ-FancontrolinPWMmodefor4-pinchassisfan.
[DCmode] EnablesthechassisQ-FancontrolinDCmodefor3-pinchassisfan.
[Disabled] DisablesthechassisQ-Fancontrolfeature.
ThefollowingitemsappearonlywhenyousettheChassisFan1/2Q-FanControlto[PWM
Mode] or [DC Mode].
Chassis Fan 1/2 Q-Fan Source [CPU]
Thisitemcontrolstheassignedfanaccordingtotheselectedtemperaturesource.
Congurationoptions:[CPU][MB]
Chassis Fan 1/2 Speed Low Limit [600 RPM]
Thisitemallowsyoutodisableorsetthechassisfanwarningspeed.Congurationoptions:
[Ignore][200RPM][300RPM][400RPM][500RPM][600RPM]
Chassis Fan 1/2 Profile [Standard]
Thisitemallowsyoutosettheappropriateperformancelevelofthechassisfan.
[Standard] Setsto[Standard]tomakethechassisfanautomaticallyadjustdepending
onthechassistemperature.
[Silent] Setsto[Silent]tominimizethefanspeedforquietchassisfanoperation.
[Turbo] Setsto[Turbo]toachievemaximumchassisfanspeed.
[Manual] Setsto[Manual]toassigndetailedfanspeedcontrolparameters.
ThefollowingfouritemsappearonlywhenyousetChassis Fan 1/2 Profile to[Manual].
Chassis Fan 1/2 Upper Temperature [70]
Usethe<+>or<->keystoadjusttheupperlimitoftheCPUtemperature.Thevalues
rangefrom40°Cto75°C.
Chassis Fan 1/2 Max. Duty Cycle(%) [100]
Usethe<+>or<->keystoadjustthemaximumchassisfandutycycle.Thevalues
rangefrom60%to100%.Whenthechassistemperaturereachestheupperlimit,the
chassisfanwilloperateatthemaximumdutycycle.
Chassis Fan 1/2 Middle Temperature [45]
Usethe<+>or<->keystosetthevalueforChassisFanMiddleTemperature.
Chassis Fan 1/2 Middle Duty Cycle(%) [60]
Usethe<+>or<->keystoadjustthechassisfanmiddledutycycle.Thevaluesrange
from60%to100%.
Chassis Fan 1/2 Lower Temperature [40]
Usethe<+>or<->keystoadjustthechassisfans’lowertemperature.Thevalues
rangefrom40°Cto75°C.
2-38 Chapter 2: Getting started
