Adding items to My Favorites
ToaddBIOSitems:
1. Press<F3>onyourkeyboardorclick fromtheBIOSscreentoopen
SetupTreeMapscreen.
2. OntheSetupTreeMapscreen,selecttheBIOSitemsthatyouwanttosavein
MyFavoritesscreen.
3. Selectanitemfrommainmenupanel,thenclickthesubmenuthatyouwanttosaveas
favoritefromthesubmenupanelandclick .
YoucannotaddthefollowingitemstoMyFavoriteitems:
• User‑manageditemssuchaslanguageandbootorder
4. ClickExit (ESC)orpress<esc>keytocloseSetupTreeMapscreen.
5. GotoMyFavoritesmenutoviewthesavedBIOSitems.
Main menu
panel
Submenu
panel
Selected
shortcut items
ASUS H170M-PLUS 2‑17
