Asus b150m-a d3 [33/51] Chapter 2 bios information
![Asus b150m-a d3 [33/51] Chapter 2 bios information](/views2/1162413/page33/bg21.png)
2.1 Managing and updating your BIOS
Save a copy of the original motherboard BIOS le to a USB ash disk in case you need
to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS
Update utility.
2.1.1 EZ Update
EZ Update is a utility that allows you to automatically update your motherboard’s softwares,
drivers and the BIOS version easily. With this utlity, you can also manually update the saved
BIOS and select a boot logo when the system goes into POST.
To launch EZ Update, click EZ Update on the AI Suite 3 main menu bar.
BIOS information
2
EZ Update requires an Internet connection either through a network or an ISP (Internet
Service Provider).
Click to automatically
update your
motherboard’s driver,
software and firmware
Click to find and
select the BIOS
from file
Click to select
a boot logo
Click to update
the BIOS
ASUS B150M-A D3 2-1
