Asus b150m-a d3 [9/51] B150m a d3 specifications summary
![Asus b150m-a d3 [9/51] B150m a d3 specifications summary](/views2/1162413/page9/bg9.png)
ix
BIOS features
128Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3,
F6 Qfan Control, F3 My Favorites, Quick Note, Last Modied log, F12
PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Operating System
Support
Windows
®
10 (64-bit)
Windows
®
8.1 (64-bit)
Windows
®
7 (64-bit/32-bit)
* Please refer to ASUS official website and download “Windows
®
7 Installation
Guide” and “EZ Installer” to install Windows
®
7.
Form factor
uATX form factor: 9.2”x 7.9” (23.4cm x 20.1cm)
B150M-A D3 specifications summary
Specications are subject to change without notice.
