Asus transformer book flip tp200sa, 90nl0081-m03510 [21/104] Front side

Notebook PC E-Manual

Front Side

Status indicators

The status indicators help identify the current hardware status of

your Notebook PC.

Power indicator

The power indicator lights up when the Notebook PC

is turned on.

Two-color battery charge indicator

The two-color LED provides a visual indication of the

battery’s charge status. Refer to the following table

for details:
