ASUS B150-A
1-3
Clear RTC RAM (2-pin CLRTC)
ThisheaderallowsyoutocleartheCMOSRTCRAMdataof
thesystemsetupinformationsuchasdate,time,andsystem
passwords.
To erase the RTC RAM:
1. TurnOFFthecomputerandunplugthepowercord.
2. Useametalobjectsuchasascrewdrivertoshortthe
twopins.
3. PlugthepowercordandturnONthecomputer.
4. Holddownthe<Del>keyduringthebootprocessand
enterBIOSsetuptore-enterdata.
CLRTC
+3V_BAT
GND
PIN 1
Ifthestepsabovedonothelp,removetheonboardbatteryandshortthetwopinsagain
tocleartheCMOSRTCRAMdata.AfterclearingtheCMOS,reinstallthebattery.
System panel connector (20-5 pin PANEL)
Thisconnectorsupportsseveralchassis-mountedfunctions.
USB 3.0 connector (20-1 pin USB3_12)
ConnectaUSB3.0moduletothisconnectorforadditionalUSB3.0frontorrear
panelports.ThisconnectorcomplieswithUSB3.0specicationsandprovidefaster
datatransferspeedsofupto5Gbps,fasterchargingtimeforUSB-chargeable
devices,optimizedpowerefciency,andbackwardcompatibilitywithUSB2.0.
USB 2.0 connector (10-1 pin USB1112)
ConnecttheUSBmodulecabletothisconnector,theninstallthemoduletoaslot
openingatthebackofthesystemchassis.ThisUSBconnectorcomplieswithUSB
2.0specicationsandsupportsupto480Mbpsconnectionspeed.
Serial port connector (10-1 pin COM)
Connecttheserialportmodulecabletothisconnector,theninstallthemoduletoa
slotopeningatthebackofthesystemchassis.
Digital audio connector (4-1 pin SPDIF_OUT)
ConnecttheS/PDIFOutmodulecabletothisconnector,theninstallthemoduleto
aslotopeningatthebackofthesystemchassis.
SPDIF_OUT
+5V
SPDIFOUT
GND
PIN 1
