![Asus b150-a [7/27] B150 a specifications summary](/views2/1162949/page7/bg7.png)
vii
B150-A specifications summary
(continued on the next page)
Specifications
Audio
Realtek
®
ALC887 8-channel High Denition Audio CODEC
- Supports Jack-Detection and Front Panel Jack-Retasking
Gaming Audio:
- LED-illuminated design - Brighten up your build with the gorgeous illuminated
audio trace path.
- Audio Shielding: Ensures precision analog/digital separation and greatly
reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to
guard the quality of the sensitive audio signals
- Premium Japanese-made audio capacitors: Provide warm, natural and
immersive sound with exceptional clarity and delity
ASUS unique
features
Proven Quality
ASUS 5X PROTECTION II
- ASUS LANGuard - 2.5X higher surge tolerance
- ASUS Overvoltage Protection - World-class circuit-protection power design
- ASUS DIGI+ VRM - 6 Phase digital power design
- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage
prevention
- ASUS Stainless Steel Back I/O - 3x more durable corrosion-resistant coating
Superb Performance
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
UEFI BIOS
- Most advanced options with fast response time
ASUS EPU
- EPU
USB 3.0 Boost
- featuring speedy USB 3.0 transmission
