vi
B150-A specifications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS B150-A motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
Application DVD
1 x Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
Specifications
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7 / i5 / i3 / Pentium
®
/ Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
B150 Express Chipset
Memory
4 x DIMM, maximum 64 GB, DDR4 2133 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please
refer to Memory QVL (Qualified Vendors List) for details.
** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
*** The maximum memory frequency supported varies by processor.
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode)
2 x PCI Express 3.0/2.0 x1 slots
3 x PCI slots
Multi-GPU
Support
Supports AMD
®
CrossFireX™ Technology
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
- Supports DVI-D with maximum resolution of 1920 x 1200 @ 60Hz
Maximum shared memory of 1024 MB
Storage
Intel
®
B150 Express Chipset
- 4 x Serial ATA 6.0 Gb/s connectors (gray)
LAN
Realtek
®
8111GR Gigabit LAN
USB
Intel
®
B150 Express Chipset - supports ASUS USB 3.0 Boost
- 4 x USB 3.0/2.0 ports (2 ports at mid-board; 2 ports at the back panel, blue)
Intel
®
B150 Express Chipset
- 6 x USB 2.0/1.1 ports (2 ports at mid-board; 4 ports at the back panel)
