1-14
Chapter 1: Product Introduction
IRQ assignments for this motherboard
A B C D E F G H
PCIEX1_1 - - - - - - - shared
PCIE_X16/X8_1 shared - - - - - - -
PCI1 - - - - shared - - -
PCIEX1_2 shared - - - - - - -
PCIE_X8_2 - - - - shared - - -
PCI2 - - - - - shared - -
M.2PCIEX4SLOT - - - - shared - - -
HDAudio shared - - - - - - -
IntelLANController - - shared - - - - -
SATAController - - - shared - - - -
USB1.1Controller1 - - shared - - - - -
USB1.1Controller2 - - - - shared - - -
USB1.1Controller3 - - - - - - shared -
USB1.1Controller4 - - shared - - - - -
USB2.0Controller1 - shared - - - - - -
USB2.0Controller2 - - - - - shared - -
USB2.0Controller3 - - - - - - - shared
AsmediaUSB3.1Controller shared - - - - - - -
AsmediaUSB3.0Controller - shared - - - - - -
• WerecommendthatyouprovidesufcientpowerwhenrunningCrossFireX™mode.
• ConnectachassisfantothemotherboardconnectorlabeledCHA_FAN1-3when
usingmultiplegraphicscardsforbetterthermalenvironment.
VGA configuration
PCI Express 2.0 operating mode
PCIe 2.0 x16/x8_1 PCIe 2.0 x8_2
SingleVGA/PCIecard
x16(singleVGA
recommended)
N/A
DualVGA/PCIecard x8 x8
