Z10PE-D16 WS specifications summary
(continues on next page)
CPU
Dual Intel
®
Socket 2011-3 for Xeon
®
processor E5-2600 v3 product
family
QPI 6.4 / 8.0 / 9.6 GT/s
* Refer to www.asus.com for CPU support list
Chipset
Intel
®
C612 PCH
Memory
DDR4 16 x DIMM (4-channel per CPU, 8 DIMM per CPU), Max.
1024GB
DDR4 2133*/1866/1600 MHz RDIMM/LR-DIMM/NVDIMM
Quad channel memory architecture
* 2133MT/s at 1 DPC only.
** Refer to www.asus.com for the memory QVL (Qualified Vendors Lists).
Expansion slots
Slot 1: PCIE x16 (x8 Gen3 Link)
Slot 2: PCIE X16 (x16 Gen3 Link)
Slot 3: PCIE x16 (x8 Gen3 Link)
Slot 4: PCIE X16 (x16 Gen3 Link)
Slot 5: PCIE x16 (x16 Gen3 Link)
Slot 6: PCIE x16 (x16 Gen3 Link)
* This motherboard is ready to support PCIe 3.0 specification. Functions
will be available when using PCIe 3.0-compliant devices. Refer to
www.asus.com for the latest updates and information.
VGA Output
ASpeed AST2400 32MB
VGA port (with bracket)
Supports VGA with max. resolution 1920 x 1200 at 60Hz
Multi-GPU support
Supports NVIDIA
®
3-Way SLI™ Technology
Supports AMD
®
Quad-GPU CrossFireX™ Technology
Storage
Intel
®
C612 Chipset:
10 x SATA 6Gb/s ports (6 x right angle connectors from SATA
controller, 4 x vertical connectors from sSATA controller)* with Intel
®
RSTe RAID 0, 1, 5 and 10 support (for Windows only)
1 x Discrete M.2 Socket 3*
LSI MegaRAID driver supports software RAID 0, 1 and 10 (Windows
& Linux)**
* M.2 Socket 3 supports M Key and type 2260/2280/22110 storage devices,
and M.2 share bandwidth with SSATA Port 4.
** LSI MegaRAID only supports SATA Controller.
LAN
2 x Intel
®
I210AT Gigabit LAN controller
1 x Management Port
