11 di 14
! enter the operating parameters (ref. sect.. 5.3 Adjustments);
! select the language in which the messages are given.
! set running parameters
5.1 Controls
The UPS has the following controls:
! UPS secure powering (protection against accidental powering);
! UPS stopping (to prevent accidental power-offs while allowing the UPS to be quickly
shutdown in an emergency. The button must remain depressed for at least 3 seconds);
! buzzer silencer;
! keyboard to browse the menus on the display, set parameters, confirming the selected
functions and quitting.
5.2 Measurements
The UPS can manage the following measurements and show the relevant values on the display:
INPUT
Current:
! Root-mean-square
value
! Peak value
! Peak factor
Voltage:
! Root-mean-square
value
Power:
! Apparent
! Active
Power factor
Frequency
OUTPUT
Current:
! Root-mean-square
value
! Peak value
! Peak factor
Voltage:
! Root-mean-square
value
Power:
! Apparent
! Active
Power factor
Frequency
BATTERIES
! Charging current
! Discharging
current
! Battery operation
time
! Residue capacity
! Battery voltage
! Date/time of last
battery calibration
MISCELLANEOUS
! Internal
temperature of
individual power
modules
! Ambient
temperature
HISTORIC DATA
! N° of bypass
interventions
! N° thermal protection
interventions with date
and time
! Number of battery
commutations
! Number of total
discharges
Overall time of:
! Battery operation
! Mains operation
5.3 Adjustments
The will UPS allow the following adjustments to be made and shown on the display:
OUTPUT
! Voltage
! Frequency
! Redundancy N+X
INPUT
! Enable synchronizing
! Extended
synchronizing interval
BYPASS
! Enabling
! Forced
! Actuation sensitivity
! Off line mode
! Load waiting mode
