![Legrand Keor Т 20 kВA с разделительным трансформатором [2/2] Keor t 20 kva](/views2/1165683/page2/bg2.png)
1. GENERAL SPECIFICATIONS (continue)
3 102 32
KEOR T 20 kVA with insulation transformer
2/2
OUTPUT
Voltage (380/400/415)
Frequency (50Hz/60Hz)
BATTERY
Battery String
Battery Capacity
PARALLEL MODE
Parallel Mode
(Enable/Disable(Single))
UPS ID
Redundancy (+1, +2, …, +7)
Operation Mode (Redundancy
Power Increase)
COMMAND MENU
Priority (Online (Inverter) /Green (Bypass))
Battery Test (KEOR T tests the battery automatically once
each 90 days)
Maintenance (Rectifier,Inverter, Bypass, Load Supply – YES/NO)
RELAY FUNCTIONS
Relay 1 (General Alarm as standard. Can be adjusted from 7 different
alarms)
Relay 2 (Input Failure as standard. Can be adjusted from 7 different
alarms)
Relay 3 (Battery Failure as standard. Can be adjusted from 7
different alarms)
Relay 4 (Output Failure as standard. Can be adjusted from 7 different
alarms)
OPTIONS
Alarm Voice (Enable/Disable)
Key Voice (Enable/Disable)
Warning Window (Enable/Disable)
OTHER
Display Brightness (0 to 100)
Emergency Power Off (NC/NO)
Generator Mode (NC/NO)
ModBus ID
Time (hh:mm. Required for Event Log stamp)
Date (dd:mm:yyyy. Required for Event Log stamp)
Language (English)
The UPS allows also the following settings by display:
2. TECHNICAL SPECIFICATIONS
General Specifications
UPS Topology On line double conversion VFI SS 111
Architecture of the UPS
Stand alone, transformerless, On-Site
Paralleling
In/Out phase Configuration
Three phase-Three phase (Optional Three
phase-Mono phase)
Neutral Neutral Passing through
Switching Technology 3-Level IGBT
Backfeed Protection Internal, standard
Output wave form on mains operation Sinusoidal
Output wave form on battery operation Sinusoidal
Standards EN 62040-1, EN 62040-2, EN 62040-3
Input
Nominal Voltage 400 3ph+N+PE
Voltage Range
338 - 459 Ph-Ph full load
208 - 459 Ph-Ph half load"
Frequency 45 - 65Hz
THDin < 7% at full load
Power Factor > 0.99
Output with mains (AC-AC)
Nominal Voltage 380, 400, 415 3ph+N+PE
Nominal Power 20.000 VA
Active Power 18.000 W
Voltage variation (static) ± 1%
THDv on nominal power (linear load) < 2%
THDv on nominal power (non-linear load) < 4%
Frequency 50 Hz or 60 Hz (selectable)
Frequency tolerance ± 0,1% Synchronized with input frequency
Current Crest Factor 2,5:1 accordingly to IEC 62040-3
Overload capability:
10 min
60 sec
125% load rate with no bypass transfer
150% load rate with no bypass transfer
Bypass
Nominal Voltage 400 3ph+N+PE
Voltage Range ±10% (adjustable)
Frequency ±3Hz (adjustable)
Bypass type Static and electro-mechanic
Transfer time Zero
Manual Bypass Built-in
Output in battery Operation (DC-AC)
Nominal Voltage 380, 400, 415 3ph+N+PE
Nominal Power 20.000 VA
Active Power 18.000 W
Voltage variation (static) ± 1%
THDv on nominal power (linear load) < 2%
THDv on nominal power (non-linear load) < 4%
Frequency 50 Hz or 60 Hz (selectable)
Frequency tolerance ± 0,01% free run
Current Crest Factor 2,5:1 accordingly to IEC 62040-3
Overload capability:
10 min
60 sec
125%
150%
Battery
Type Lead Acid, sealed, free maintenance VRLA
Unit Capacity 7 or 9 Ah (12V)
Nominal UPS Battery Voltage ±360 Volt DC
Max. n. of possible internal battery - 1345H 60pcs
Max. n. of possible internal battery - 1650H 120pcs
Battery charger type IGBT Rectifier also charges batteries
Charging Cycle
Intelligent with boost charge and advanced
management"
Max Charging Current without derating 2 A
Environmental specs
Noise level @ 1m < 55dBA
Operating temperature range from 0°C to +40°C
Stock temperature range from -20°C to +50°C
Humidity range 20-95% not condensing
Protection degree IP20
Mechanical and Miscellaneous
Net Weight 255 kg
Dimensions (WxHxD) 400 x 1345 x 800 mm
Colour
Enclosure: RAL 7016
Front Door Metal: RAL 9005
Communication Interface
1 serial port RS232, 1 RS485,
1 smart port for internal SNMP,
4 Dry Contacts, 1 EPO, 1 GENSET
Input/Output connections 3Ph + N + PE
Input/Output Circuit Breaker 63A
Internal Battery Shelf Drawer type
The UPS KEOR T has the CE Mark accordingly with the EU Directives
73/23, 93/68, 89/336, 92/31, 93/68 and it complies with following
standards:
• EN62040-1“Generalrulesforelectricsafety”
• EN62040-2“Electromagneticcompatibilityandimmunity(EMC)”
• EN62040-3“Performancesandtestingrules”
Legrand KEOR T displays up to 380 last events. Events are stored in
EEPROM using FIFO method. Order number of last occurred event is
001 and the last event in the list is erased when there are 380 events.
Technical sheet: UPS-LGR-0096/GB Last update: 01/04/2015 01/04/2015
