Use this mode if printing is faint or contains foreign substances. This method of cleaning consumes the least amount of

ink.

It takes about five minutes to complete.

• Head Cleaning B

Use this mode if no ink is ejected at all, or if Head Cleaning A does not solve the problem.

It takes about six minutes to complete.

Important

• Do not remove the Maintenance Cartridge or ink tanks during either Head Cleaning A or Head Cleaning B.

Ink may leak or an error may occur.

• If printing does not improve even if you execute Head Cleaning B, try repeating Head Cleaning B once or

twice. If this still does not improve printing, the Printhead may have reached the end of its useful life. Con-

tact your Canon dealer for assistance.

Note

• Nozzles are periodically checked to ensure they are clear. Configure the settings on the Control Panel menu

in Nozzle Check. (See "Menu Settings.") →P.914

Perform cleaning as follows.

1. On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab (

Note

• If the Tab Selection screen is not displayed, press the Menu button.

2. Press the OK button.

The Set./Adj. Menu is displayed.

3. Press ▲ or ▼ to select Maintenance, and then press the OK button.

4. Press ▲ or ▼ to select Head Cleaning, and then press the OK button.

5. Press ▲ or ▼ to select Head Cleaning A or Head Cleaning B, and then press the OK button.

Head cleaning is now executed.

6. Print a test pattern to check the nozzles, and determine whether cleaning has cleared the nozzles. (See "Checking

for Nozzle Clogging.")

→P.980

Replacing the Printhead

When to replace the Printhead

This printer is equipped with two printheads.

Maintenance and Consumables

Printheads
