Canon imagePROGRAF iPF750 [755/878] Printheads
![Canon imagePROGRAF iPF750 [755/878] Printheads](/views2/1165713/page755/bg2f3.png)
Printheads
Printhead ......................................................................................................................................................... 739
Checking for Nozzle Clogging ........................................................................................................................ 739
Cleaning the Printhead ................................................................................................................................... 740
Replacing the Printhead ................................................................................................................................. 741
Printhead
A replacement Printhead.
• Printhead PF-04
Note
• For instructions on replacing the Printhead, see "Replacing the Printhead." →P.741
Checking for Nozzle Clogging
If printing is faint or affected by banding in different colors, make sure the Printhead nozzles are clear by printing a test
pattern to check the nozzles.
Note
• Nozzles are periodically checked to ensure they are clear. Configure the settings on the Control Panel menu
in Nozzle Check. (See "Menu Settings.") →P.673
1. Load unused paper.
• Attaching the Roll Holder to Rolls →P.575
• Loading Rolls in the Printer →P.579
• Loading Sheets in the Printer →P.602
2. On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab ( ).
Maintenance and Consumables
>
Printheads
>
iPF750
Printhead
10
739
