Concord transformer t [10/15] _ securing the child with the three point belt

pressed whilst moving the head section (01) into the

required position. The CONCORD TRANSFORMER

can be continuously adjusted to the right size and is

locked into the current position when the adjustment

button (04) is released.

3938

The shoulder belt guide (06) should be slightly above the top

of the child‘s shoulder. At the same time, the shoulder belt

should pass centrally between the child‘s neck and the outer

edge of the shoulder.

To adjust the CONCORD

TRANSFORMER to the size of

the child, gently press the head

section (01) down. Now press the

size adjustment button (04) on the

back of the backrest and keep it

_ SECURING THE CHILD WITH THE THREE-POINT BELT

Seat your child well back in the seating area. Pass the

three-point belt across the front of the child to the seat

belt lock, and fasten it in the same way as for an adult.

(There must be an audible click.)

Now position the belts. Pass the lap belt across both

sides and the diagonal belt on the side of the seat belt

lock through the lap belt guide (03).

Finally, pass the diagonal belt through the provided

shoulder belt guide (06).

Make sure the belt passes

inside the securing hook.
