Setup Menu

When the main page appears, find the Setup menu in the left side of

the screen (Figure 15). Click on the setup item that you want to

configure. There are eleven options: Port Settings, VLAN Settings,

Trunk Setting, Mirror Setting, Device Status, Statistic, System Settings,

Trap Setting, Password Setting, Backup Setting and Reset Setting as

shown in the Main Menu screen.

Figure 15. Setup menu

Configuring Setup Setting

Find that there are four items, including Port Settings, VLAN Settings,

Trunk Settings and Mirror Settings in Setup menu.

Port Settings

In Port Settings menu (Figure 16), this page will show each port’s

status, press the ID parameter to set each port’s Speed, Flow Control,

QoS priority and Link Status. When you need to renew the posted

information, press the “Refresh” button.
