Configuring the Switch

The 16-Port 10/100/1000Mbps Gigabit Ethernet Web Smart Switch

has a Web GUI interface for smart switch configuration. The Switch

can be configured through the Web Browser. A network administrator

can manage, control and monitor the switch from the local LAN. This

section indicates how to configure the Switch to enable its smart

functions including:

 Port Setting (Speed/Disable, Duplex mode, Flow Control and

Port base QoS)

 Virtual LAN Group setting (VLAN)



Trunking

 Port Mirroring

 System Setting

 Device status and Statistic

Before you configure this device, note that when the Web Smart

Switch is configured through an Ethernet connection, make sure the

manager PC must be set on same the IP network. For example, when

the default network address of the default IP address of the Web Smart

Switch is 192.168.0.1, then the manager PC should be set at

192.168.0.x (where x is a number between 2 and 254), and the default

subnet mask is 255.255.255.0.

Open Internet Explorer 5.0 or above Web browser.

Enter IP address http://192.168.0.1

(the factory-default IP address

setting) to the address location.

Figure 12.
