Dell ultrasharp u2715h [7/63] Front view
![Dell ultrasharp u2715h [7/63] Front view](/views2/1166467/page7/bg7.png)
About Your Monitor | 7
monitor).
∞
Energy Saver feature for Energy Star compliance.
∞
Security lock slot.
∞
Stand lock.
∞
Capability to switch from wide aspect to standard aspect ratio while maintaining
the image quality.
∞
EPEAT Gold Rating.
∞
U2715H monitor is BFR/PVC-free (Halogen-free) excluding external cables.
∞
TCO-Certified Displays.
∞
Meets NFPA 99 leakage current requirements.
∞
Arsenic-Free glass and Mercury-Free for the panel only.
∞
High Dynamic Contrast Ratio (2,000,000:1).
∞
0.5 W standby power when in the sleep mode.
∞
Energy Gauge shows the energy level being consumed by the monitor in real
time.
∞
Analogue backlight dimming control for flicker free display.
Identifying Parts and Controls
Front View
Front panel controls
2 31
Label Description
1 Function buttons (For more information, see
Operating the Monitor)
2 Power LED indicator
3 Power On/Off button
