32
Both (transmit and receive) mode: this mode will duplicate both the
data transmit from and data that send to the source port, then it will
forward to the sniffer port.
Figure 21.
Device Status
Click on the “Status” to present the device status on this screen, it will
show the System Status, Port Status, VLAN Status, Trunk Status and
Mirror Status..
Press “Refresh” when you need to renew the posted information.
System Setting
The System Setting includes the System name, Location name, Login
Timeout, IP Address, Subnet Mask and Gateway. Through the Web
Management Utility, you can easily recognize the device by using the
System Name and the Location Name.
The Login Timeout is to set the idle time-out for security issue, when
there is no action when running the Web Smart Utility and the time is
up, you must re-login to Web Smart Utility before you set the Utility.
Fill up the IP Address, Subnet Mask and Gateway for the device.
