37
TECHNICAL SPECIFICATIONS
General
Standards IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x Full Duplex Flow Control
Protocol CSMA/CD
Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-duplex)
Gigabit Ethernet: 2000Mbps (full-duplex)
Topology Star
Network Cables
10BASET: 2-pair UTP Cat. 3, 4, 5; up to 100m
100BASE-TX: 2-pair UTP Cat. 5; up to 100m
1000BASE-T: 4-pair UTP Cat. 5; up to 100m
Number of Ports 24 × 10/100Mbps Auto-MDIX RJ45 ports
2 × 10/100/1000Mbps Auto-MDIX RJ45 ports
Physical and Environmental
AC inputs 100-240V AC, 50-60 Hz internal universal power supply
Power Consumption 16Watts (Max)
Temperature
Operating: 0° ~ 40° C, Storage: -10° ~ 70° C
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions 440 x 140 x 44 mm (W x H x D)
EMI: FCC Class A, CE Mark Class A, VCCI Class A
Safety: cUL(UL60950), CB(IEC60950)
