Flat Panel Specifications
Model U2412M
Screen type Active matrix - TFT LCD
Panel type IPS
Screen dimensions 60.96 cm (24-inches viewable image size)
Preset display area 518.4 (H) X 324.0 (V) mm
Horizontal 518.4 mm (20.3 inches)
Vertical 324.0 mm (12.7 inches)
Pixel pitch 0.27 mm
Viewing angle
178° (vertical) typical
178° (horizontal) typical
Luminance output 300 cd/m²(typical)
Contrast ratio 1000 to 1 (typical), 2M to 1 (typical Dynamic Contrast On)
Faceplate coating Antiglare with hard-coating 3H
Backlight LED edgelight system
Response time 8 ms gray-to-gray (typical)
Color depth 16.7 million colors
Color gamut 82%*
*[U2412M] color gamut (typical) is based on CIE1976 (82%) and CIE1931 (72%) test standards.
Resolution Specifications
Model U2412M
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 50 Hz to 61 Hz (automatic)
Maximum preset resolution 1920 x 1200 at 60 Hz
Supported Video Modes
Model U2412M
Video display capabilities (DVI & DP playback)
480p, 576p, 720p, 1080p, 576i,
1080i
Preset Display Modes
U2412M
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (Horizontal/Vertical)
VESA, 720 x 400 31.5 70.0 28.3 -/+
VESA, 640 x 480 31.5 59.9 25.2 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1600 x 1200 75.0 60.0 162.0 +/+
VESA, 1680 x 1050 64.7 59.9 119.0 +/-
VESA, 1920 x 1080 66.6 59.9 138.5 +/-
VESA, 1920 x 1200 74.0 60.0 154.0 -/+
Electrical Specifications
Model U2412M
