Ensto eco16lcdj+e, для теплого пола [18/56] Technical data

TECHNICAL DATA

Operating voltage 230VAC -15%, +10%, 50Hz

Maximum load 3600W

Fuse 16A

Switch connection 2-pole

Operating temperature 0°C …+30°C

Protection class IP21

Floor sensor NTC, 47kOhm @ +25°C, 4m, extendable max.10m

Temperature change control 230V

Display LCD

Connector Screw terminal

Parameter Options / Range Default

Method of the temperature

control

Room thermostat (A)

Floor thermostat (F)

Combination thermostat (AF) X

Power control thermostat (P)

Room thermostat (A) Range +5°C…+40°C 21°C

Floor thermostat (F) Range +5°C…+60°C 21°C

Combination thermostat (AF) Range +5°C…+40°C 21°C

Floor temperature restriction

min. +5°C…+60°C

20°C

Floor temperature restriction

max. +5°C…+60°C

45°C

Power control thermostat (P) Range 0…10 5

Floor temperature restriction

max. +5°C…+60°C

45°C

Temperature change Range +5°C…+40°C 16°C

The warranty period for ENSTO Eco thermostats is 2 years from the date of purchase but no

longer than 3 years from the date of manufacture. Warranty conditions, see www.ensto.com.
