Foxconn nt-i1500, 0h0wbae [16/37] System memory system memory size
![Foxconn nt-i1500, 0h0wbae [16/37] Main menu](/views2/1167515/page16/bg10.png)
3
11
Main Menu
memory test begins and before the operating system boot begins. Once you enter the BIOS Set-
up Utility, the Main Menu will appear on the screen. The Main Menu provides System Overview
navigate between menu screens.
System BIOS
► Project Version
service people if a BIOS upgrade is needed.
► Build Date
This item shows the BIOS building date.
► EC Version
It displays the current EC version.
Processor
► Genuine Intel (R) CPU
This item shows the current CPU name.
► Core Frequency
It shows the core frequency of the processor.
► Count
It shows the total number of cores.
System Memory
►System Memory Size
System BIOS
EC Version 12.F1.01
Processor
Genuine Intel (R) CPU @
Core Frequency 2.13 GHz
Count 2
System Memory
System Memory Size 2048 MB2048 MB
MAC Address
Onboard RTL8111F LAN 00-E0-4C-69-00-01
[Mon 11/07/2011]
System Time [15:35:35]
Access Level Administrator
: Select Screen
: Select Item
Enter: Select
+/-: Change Opt
F7:
(When Access Level is Administator)
F10: Save & Exit
ESC: Exit
Version 2.13.1216. Copyright (C) 2002-2011 Foxconn, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced Power Security BootOptions Save & Exit
Main
