► Bootup Num-Lock
available settings are: On and Off (default).
► IGFX-Boot Type
► High Precision Timer
This item is used to enable or disable the high precision timer.
Integrated Peripherals
Onboard LAN Controller [Enabled]
Onboard USB3.0 Controller [Enabled]
Onboard USB Controller
Legacy USB Support [Enabled]
: Select Screen
: Select Item
Enter: Select
+/-: Change Opt
F7:
(When Access Level is Administator)
F10: Save & Exit
ESC: Exit
Version 2.13.1216. Copyright (C) 2002-2011 Foxconn, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced Power Security BootOptions Save & Exit
Main
Advanced
► Onboard LAN Controller
This item is used to enable or disable the onboard LAN controller.
► Onboard LAN Option ROM
This item is used to enable or disable the onboard LAN Option ROM.
► Onboard Audio Controller
This item is used to enable or disable the onboard audio controller.
► Onboard USB3.0 Controller
This item is used to enable or disable the onboard USB3.0 Controller.
Onboard USB Controller
► Legacy USB Support
This item is used to enable the support for USB devices on legacy OS. If you have a USB
keyboard or mouse, set to enabled.
[Enabled]: This option will enable the legacy USB support.
